UTC N-CHANNEL POWER MOSFET
|
UTC N-CHANNEL POWER MOSFET
|
Type Designator: 75N75
- Find numerous efficient original 75n75 to perform voltage, switch controlling and other electronic functions. These original 75n75 are ideal power management components.
- MOSFET symbol showing the integral reverse p - n junction diode- 14 A Pulsed Diode Forward Currenta ISM- 56 Body Diode Voltage VSD TJ = 25 °C, IS = 14 A, VGS = 0 Vb-2.5 V Body Diode Reverse Recovery Time trr TJ = 25 °C, IF = 14 A, dI/dt = 100 A/μsb - 150 280 ns Body Diode Reverse Recovery Charge Qrr.
Offer 75N75 from Kynix Semiconductor Hong Kong Limited.FETs - Single MOSFET N CH 75V 78A TO-220. Shop powered by PrestaShop.
Type of Transistor: MOSFET
Type of Control Channel: N -Channel
Maximum Power Dissipation (Pd): 300 W
Maximum Drain-Source Voltage |Vds|: 75 V
Maximum Gate-Source Voltage |Vgs|: 20 V
Maximum Drain Current |Id|: 80 A
Maximum Junction Temperature (Tj): 175 °C
Rise Time (tr): 208 nS
Drain-Source Capacitance (Cd): 773 pF
Maximum Drain-Source On-State Resistance (Rds): 0.0095 Ohm
Package: TO-220TO-220F1TO-220FTO-263
75N75 Transistor Equivalent Substitute - MOSFET Cross-Reference Search
75N75 Datasheet (PDF)
0.1. stp75n75f4.pdf Size:479K _st
STP75N75F4N-channel 75 V, 0.0092 typ., 78 A STripFET DeepGATEPower MOSFET in a TO-220 packageDatasheet production dataFeaturesTABType VDSS RDS(on) max IDSTP75N75F4 75 V
0.2. utt75n75.pdf Size:164K _utc
UNISONIC TECHNOLOGIES CO., LTD UTT75N75 Preliminary Power MOSFET 80A, 75V N-CHANNEL POWER MOSFET DESCRIPTION The UTC UTT75N75 is n-channel enhancement mode power field effect transistors with stable off-state characteristics including 1fast switching speed and low thermal resistance. It is usually used TO-220in the telecom and computer applications. FEATURES * RDS(O
0.3. 75n75.pdf Size:218K _utc
UNISONIC TECHNOLOGIES CO., LTD 75N75 Power MOSFET 80A, 75V N-CHANNEL POWER MOSFET 11TO-220 TO-220F DESCRIPTION The UTC 75N75 is n-channel enhancement mode power field effect transistors with stable off-state characteristics, fast switching 1speed, low thermal resistance, usually used at telecom and 1computer application. TO-220F1 TO-220F2 FEATURES * RDS(ON)
0.4. tsm75n75cz.pdf Size:62K _taiwansemi
TSM75N75 75V N-Channel Power MOSFET TO-220 PRODUCT SUMMARY Pin Definition: 1. Gate VDS (V) RDS(on)(m) ID (A) 2. Drain 3. Source 75 11 @ VGS =10V 75 Features Block Diagram Advanced Trench Technology Low RDS(ON) 11m (Max.) Low gate charge typical @ 81nC (Typ.) Low Crss typical @ 339pF (Typ.) Ordering Information Part No. Package Packing
0.5. cjp75n75.pdf Size:104K _jiangsu
JIANGSU CHANGJIANG ELECTRONICS TECHNOLOGY CO., LTD TO-220-3L Plastic-Encapsulate MOSFETS CJP75N75 N-Channel Power MOSFET TO-220-3L DESCRIPTION The CJP75N75 uses advanced trench technology and design to provide excellent RDS(on) with low gate charge. Good stability and 1. GATE uniformity with high EAS .This device is suitable for use in PWM, 2. DRAIN load switching and gen
0.6. kmb075n75p.pdf Size:430K _kec
KMB075N75PSEMICONDUCTORN CHANNEL MOS FIELDTECHNICAL DATAEFFECT TRANSISTORGeneral Description AThis planar stripe MOSFET has better characteristics, such as fast OCswitching time, low on resistance, low gate charge and excellentFavalanche characteristics. It is mainly suitable for active power factorE DIM MILLIMETERSG_+correction , electronic lamp ballasts based o
0.7. 75n75.pdf Size:2550K _shenzhen
Shenzhen Tuofeng Semiconductor Technology Co., Ltd75N75N-Channel Enhancement Mode MOSFETFeatures Pin Description 70V/80A,RDS(ON)=5.6 m (typ.) @ VGS=10V Avalanche Rated Reliable and RuggedGDS Lead Free and Green Devices Available(RoHS Compliant) DApplicationsG Power Management for Inverter Systems.SN-Channel MOSFETNote: lead-free products contain m
0.8. br75n75.pdf Size:905K _blue-rocket-elect
BR75N75(BRCS75N75R) Rev.C Feb.-2015 DATA SHEET / Descriptions TO-220 N MOS N-CHANNEL MOSFET in a TO-220 Plastic Package. / Features ,Low gate charge, low crss, fast switching. / Applications DC/DC These devices are well suited for hig
0.9. l75n75.pdf Size:552K _lrc
LESHAN RADIO COMPANY, LTD.L75N751/7LESHAN RADIO COMPANY, LTD.L75N752/7LESHAN RADIO COMPANY, LTD.L75N753/7LESHAN RADIO COMPANY, LTD.L75N754/7LESHAN RADIO COMPANY, LTD.L75N755/7LESHAN RADIO COMPANY, LTD.L75N756/7LESHAN RADIO COMPANY, LTD.L75N757/7
0.10. cs75n75 b8h.pdf Size:843K _crhj
Mosfet 75n75
Silicon N-Channel Power MOSFET R CS75N75 B8H General Description VDSS 75 V CS75N75 B8H, the silicon N-channel Enhanced ID 100 A PD(TC=25) 230 W VDMOSFETs, is obtained by the self-aligned planar Technology RDS(ON)Typ 10.2 m which reduce the conduction loss, improve switching performance and enhance the avalanche energy. The transistor can be used in various po
0.11. cs75n75.pdf Size:63K _china
CS75N75N PD TC=25 220 W 1.4 W/ID VGS=10V,TC=25 75 AID VGS=10V,TC=100 56 AIDM 300 A VGS 20 VTjm +150 Tstg -55 +150 RthJC 0.8 /W BVDSS VGS=0V,ID=0.25mA 75 VRDS on VGS=10V,ID=48A 0.0125 0.015
0.12. ftk75n75.pdf Size:366K _first_silicon
SEMICONDUCTORFTK75N75TECHNICAL DATAID=75A Feathers: BV=75V Advanced trench process technology Rdson=10mohm Special designed for Convertors and power controls High density cell design for ultra low Rdson TO-220 Fully characterized Avalanche voltage and current Avalanche Energy 100% test Description: The FTK75N75 is a new generation of middle voltage and 123
0.13. ms75n75.pdf Size:722K _bruckewell
Preliminary Data Sheet Bruckewell Technology Corp., Ltd. MS75N75 75V N-Channel MOSFET FEATURES RDS(on) (Max 0.017 )@VGS=10V Gate Charge (Typical 85nC) Improved dv/dt Capability, High Ruggedness 100% Avalanche Tested Maximum Junction Temperature Range (175C) MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS Absolute Maximum Ratings (Tc=25C unless
0.14. ps75n75a.pdf Size:303K _prospower
PS75N75A 75V Single Channel NMOSEFT Revision : 1.0Update Date : Apr. 2011 ProsPower Microelectronics Co., LtdPS75N75A 75V Single Channel NMOSFET2. Applications 1. General Description Solenoid and relay drivers The PS75N75A uses advanced trench technology DC motor control and design to provide excellent Rds(on) with low DC-DC convertersgate charge. This device
0.15. hrs75n75v.pdf Size:199K _semihow
Fab 2014BVDSS = 70 VRDS(on) typ = 6 HRS75N75V ID = 48 A70V N-Channel Trench MOSFETTO-220FFEATURES Originative New Design Superior Avalanche Rugged Technology123 Excellent Switching Characteristics1.Gate 2. Drain 3. Source Unrivalled Gate Charge : 80 nC (Typ.) Extended Safe Operating Area Lower RDS(ON) : 6.0 (Typ.) @VGS=10V 100% Avalanche TestedAbs
0.16. hrp75n75v.pdf Size:211K _semihow
Fab 2014BVDSS = 70 VRDS(on) typ = 6 HRP75N75V ID = 48 A70V N-Channel Trench MOSFETTO-220FEATURES Originative New Design Superior Avalanche Rugged Technology123 Excellent Switching Characteristics1.Gate 2. Drain 3. Source Unrivalled Gate Charge : 80 nC (Typ.) Extended Safe Operating Area Lower RDS(ON) : 6.0 (Typ.) @VGS=10V 100% Avalanche TestedAbso
0.17. ps75n75.pdf Size:188K _sirectsemi
E L E C T R O N I C PS75N75N-Channel Enhancement Mode Field Effect Transistor - 75Amp 75Volt Application -Servomotor control -Power MOSFET gate drivers -Other switching applications Circuit Feature -Small surface mounting type D-High density cell design for low RDS(ON) -Suitable for high packing density -Rugged and reliable -High saturation current cap
75n75 Mosfet Price
0.18. st75n75.pdf Size:674K _stansontech
ST75N75 N Channel Enhancement Mode MOSFET 75.0A DESCRIPTION ST75N75 is used trench technology to provide excellent RDS(on) and gate charge. Those devices are suitable for use as load switch or in PWM applications. PIN CONFIGURATION FEATURE TO220-3L 75V/40.0A, RDS(ON) = 8m (Typ.) @VGS = 10V Super high density cell design for extremely low RDS(ON) Exceptional on-r
0.19. cs75n75b8h.pdf Size:843K _wuxi_china
Silicon N-Channel Power MOSFET R CS75N75 B8H General Description VDSS 75 V CS75N75 B8H, the silicon N-channel Enhanced ID 100 A PD(TC=25) 230 W VDMOSFETs, is obtained by the self-aligned planar Technology RDS(ON)Typ 10.2 m which reduce the conduction loss, improve switching performance and enhance the avalanche energy. The transistor can be used in various po
0.20. 75n75.pdf Size:223K _inchange_semiconductor
isc N-Channel MOSFET Transistor 75N75FEATURESDrain Current I = 75A@ T =25D CDrain Source Voltage-: V = 75V(Min)DSSStatic Drain-Source On-Resistance: R = 0.011(Max)DS(on)Minimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSSolenoid and relay driversDC motor controlDC-DC converters DCAutomotive environ
